SR626

  • Max. Lift Capacity: 2,600kg
  • Max. Lift Height: 5.79m
  • Max. Forward Reach: 3.2m
  • Engine: Yanmar 52kW Stage V diesel

Download Specifications (PDF)

Add to quote list

The Snorkel SR626 compact rough terrain telehandler is a robust performer. Designed for working in confined spaces, the telehandler offers proportional controls for precise maneuvering. Full-time 4-wheel drive and power assisted steering make this compact telehandler well-suited for construction applications.

Standard Features

  • Full-time 4-wheel drive
  • 4-wheel steer – selectable front, crab & coordinated
  • Selectable front, crab & coordinated steering modes
  • Auxiliary hydraulic circuit on the boom
  • Variable speed hydrostatic drive
  • Fender (set of 4)
  • Fully enclosed cab with heat
  • Proportional joystick
  • Illuminated gauge and switch panels
  • Colour LCD display with machine & engine diagnostics
  • Flashing beacon
  • Fixed 1200mm carriage with 1200mm floating forks
  • 2 year parts & labour, 5 year structural warranty
Max. Lift Height

5.79m
Max. Lift Capacity

2,600kg
Max. Forward Reach

3.2m
Overall Width

Stowed Height

Wheel Base

Ground Clearance

Length to fork face

Max. drive speed

27km/h
Raise/Lower Time

Outside Turning Radius

Tires

12 x 16.5
Fuel Capacity

Power Source

Hydraulic Pressure

Hydraulic Flow (per min)

Hydraulic Oil Capacity

Weight

Options

  • Special paint colours
  • Euro coupling
  • Air conditioning
  • Grammer air suspension seat
  • Front & rear LED work lights (4)
  • Work lights on boom (2)
  • Heated right exterior mirror
  • Additional rear mirror
  • Cab front glass protection grille
  • Non-marking tyres 12-16.5
  • Engine preheater 220V
  • Boom suspension & floating boom
  • Bluetooth radio, handsfree & USB socket
  • Sun curtain
  • Fixed tow hook 6 ton
  • Snorkel OnSite™ telematics

Load Chart

SR626 Load Chart

Video

Warranty

All Snorkel telescopic boom lifts are built to the highest standards and we carry out rigorous quality checks at every stage of production. To ensure our customers have peace of mind in purchasing Snorkel products, all Snorkel machines come with a five-year structural warranty, plus a two-year warranty for parts and labour. Ahern Australia is authorized to carry our Snorkel warranty repairs. For further details, please visit our Warranty page.

Specifications subject to change without notice. Photos and diagrams on this website are for promotional purposes only. Refer to appropriate operators manual for detailed instructions on the proper use and maintenance.
